Energy Storage System, Energloo^TM

• Energloo^TM is Lithium-polymer modular battery unit can be scaled to meet various energy needs. Utilizing advanced BMS, it provides longer battery life compared to other Lithium batteries in the market.

• Energloo^TM is a light weight rechargeable battery system based on environmentally friendly Lithium polymer technology, which is less than one-half weight of comparably powered lead-acid battery solutions. It also provides wide range ofoperating temperature (-20° ~ 60°C), minimal standby power consumption, minimum of 1000 cycles and high rate of power output (5C).

• The BMS installed in Energloo^TM provides cell balancing and monitors SOC level of individual cells, thermal condition, voltage, and current.

Features

• Surge Protection
• Over charging & discharging prevention
• Low voltage alarm
• Cooling System
• Cell Balacing
• Current Based SOC Estimation - (Coulomb Counting)
• RS232C. CAN Bus Interface forcommunication

Benefits

• High charge/discharge rate
• Light weight
• Extended battery life
• Wide range of operation temperature (-20° ~ 60°C)
• Power saving function
• Long shelf life
• Accurate SOC estimation
• Scalable

Energy Storage

• Energloo^TM is integrated with BMS (Battery MAnagement System) which help extend battery life and allows precise monitor/control over power flow for enhanced safety and optimal condition for the cells.

• Unlike lead-acid, NiCd, NiMH battery technologies, Lithium-polymer uses environmentally friendly materials and does not require special disposal process

	Model	PRO - 011ER084S (310V 11Ah)
	MECHANICAL
	L x W x H (mm)	1050mm x 340mm x 120mm
	Weight (Kg)	40kg
	ELECTRICAL
	Nominal voltage	310.8V (3.7V/Cell)
	Operating voltage	285.6~352.8V (3.4~4.2V/Cell)
	Nominal capacity (1C charge/ 1C discharge)	11Ah
	Recommended standard charge	0.5C (5.5A)
	Recommended standard discharge	2.0C (22A)
	Peak discharge current	5C (55A)
	Cycle Life (cycles)	1000 Cycle At 23±3°C (100% DOD)
	Communication	CAN 2.0B
	Cells in Module	84S1P
	ENERGY & PERFORMANCE
	Nominal capacity	11Ah
	Power (continuous)	6837.6Wh
	Power (peak)	17094Wh
	ENVIRONMENTAL
	Operating temperature (charge)	0~+45°C
	Operating temperature (discharge)	-20~+60°C
	Storage temperature	1month -20~+60°C, 3month -20~+45°C, 1year -20~+20°C
	Self discharge rate	< 1% (monthly at room temperature)

	Model	PRO - 200ER003S (11V 200Ah)
	MECHANICAL
	L x W x H (mm)	496mm x 459mm x 80mm
	Weight (Kg)	15kg
	ELECTRICAL
	Nominal voltage	11.1V (3.7V/Cell)
	Operating voltage	9~12.6V (3.20~4.20V/Cell)
	Nominal capacity (1C charge/ 1C discharge)	200Ah
	Recommended standard charge	10A (0.05C)
	Recommended standard discharge	10A (0.05C)
	Peak discharge current	20A (0.1C)
	Cycle Life (cycles)	1000Cycle At 23±3°C (100% DOD)
	Communication	CAN
	Cells in Module	3 (3S 1P, 200Ah)
	ENERGY & PERFORMANCE
	Nominal capacity	200Ah
	Power (continuous)	111Wh
	Power (peak)	222Wh
	ENVIRONMENTAL
	Operating temperature (charge)	0~+45°C
	Operating temperature (discharge)	-20~+60°C
	Storage temperature	1month -20~+60°C, 3month -20~+45°C, 1year -20~+20°C
	Self discharge rate	< 1% (monthly at room temperature)
